Caddy SSL Certificate Configuration

TL;DR

Caddy automatically obtains and renews Let's Encrypt certificates for any domain you serve. Just point DNS at your server, open ports 80 and 443, and Caddy handles the rest. For manual certificates, use the tls directive with file paths. Most issues come from: DNS not pointed, ports blocked, or file permissions.

Works out of the box for public DNS names. See Local Development for localhost and .local domains. Most examples use HTTP-01 challenge; see ACME Configuration for DNS-01 and wildcards.

1. Automatic HTTPS (The Magic)

The Simplest Possible Config

example.com {
    respond "Hello, secure world!"
}

That's it. Caddy will:

Obtain a certificate from Let's Encrypt
Redirect HTTP → HTTPS
Renew before expiration
Use modern TLS defaults

What Caddy Does Automatically

Feature	Default Behavior
Certificate	Let's Encrypt production
TLS Version	TLS 1.2 minimum
Cipher Suites	Modern, secure defaults
HTTP → HTTPS	Automatic redirect
OCSP Stapling	Enabled
Renewal	30 days before expiry

Requirements for Automatic HTTPS

Domain's DNS A/AAAA record points to your server
Ports 80 AND 443 accessible from internet
Not using localhost, 127.0.0.1, or .local domains
Caddy has permission to bind to ports (or use setcap/systemd)

2. Reverse Proxy with Automatic TLS

Most common use case—Caddy as TLS terminator:

app.example.com {
    reverse_proxy localhost:3000
}

api.example.com {
    reverse_proxy localhost:8080
}

Both domains get automatic certificates.

With Health Checks and Load Balancing

app.example.com {
    reverse_proxy localhost:3000 localhost:3001 {
        lb_policy round_robin
        health_uri /health
        health_interval 30s
    }
}

Preserving Client IP

app.example.com {
    reverse_proxy localhost:3000 {
        header_up X-Real-IP {remote_host}
        header_up X-Forwarded-For {remote_host}
        header_up X-Forwarded-Proto {scheme}
    }
}

3. Manual Certificate Configuration

For enterprise PKI, internal CAs, or purchased certificates:

Basic Manual Certificate

example.com {
    tls /path/to/cert.pem /path/to/key.pem
    reverse_proxy localhost:3000
}

With Certificate Chain (fullchain)

example.com {
    tls /path/to/fullchain.pem /path/to/key.pem
    reverse_proxy localhost:3000
}

Caddy expects PEM format. The cert file can contain the full chain (leaf + intermediates).

Wildcard with Manual Cert

*.example.com {
    tls /path/to/wildcard.pem /path/to/wildcard.key

    @app host app.example.com
    handle @app {
        reverse_proxy localhost:3000
    }

    @api host api.example.com
    handle @api {
        reverse_proxy localhost:8080
    }
}

Wildcard Warning: See Dangers of Wildcard Certificates for security considerations.

4. TLS Configuration Options

Customize TLS Settings

example.com {
    tls {
        protocols tls1.2 tls1.3
        ciphers TLS_ECDHE_ECDSA_WITH_AES_256_GCM_SHA384 TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384
        curves x25519 secp384r1 secp256r1
    }
    reverse_proxy localhost:3000
}

TLS 1.3 Only (High Security)

example.com {
    tls {
        protocols tls1.3
    }
    reverse_proxy localhost:3000
}

Warning: TLS 1.3-only may break older clients (Java 8, legacy middleware, some corporate proxies). Test thoroughly before enforcing. See our TLS Handshake Demo to troubleshoot connection issues.

Client Certificate Authentication (mTLS)

example.com {
    tls {
        client_auth {
            mode require_and_verify
            trusted_ca_cert_file /path/to/client-ca.pem
        }
    }
    reverse_proxy localhost:3000
}

Trust bundle options: Use trusted_ca_cert_file for a single CA file, or trusted_ca_certs (plural) if you need to specify multiple CA certificates inline. Caddy stores its own CA data in /data/caddy/pki/.

Learn more: See our mTLS Deep Dive for client certificate authentication patterns.

5. ACME Configuration

Use Let's Encrypt Staging (For Testing)

{
    acme_ca https://acme-staging-v02.api.letsencrypt.org/directory
}

example.com {
    reverse_proxy localhost:3000
}

DNS Challenge for Wildcards

{
    acme_dns cloudflare {env.CF_API_TOKEN}
}

*.example.com {
    reverse_proxy localhost:3000
}

Note: The global acme_dns option applies to all sites unless overridden per-site. If you have mixed domains across different DNS providers, configure DNS challenges per-site block instead.

Specify Email for Let's Encrypt Notifications

{
    email admin@example.com
}

example.com {
    reverse_proxy localhost:3000
}

Use ZeroSSL Instead of Let's Encrypt

{
    acme_ca https://acme.zerossl.com/v2/DV90
    acme_eab {
        key_id YOUR_KID
        mac_key YOUR_HMAC_KEY
    }
}

6. Local Development

Self-Signed for Localhost

localhost {
    tls internal
    reverse_proxy localhost:3000
}

Caddy generates a locally-trusted certificate. Run caddy trust once to add Caddy's CA to your system trust store.

Browser gotcha: Some browsers cache trust state aggressively. After running caddy trust, you may need to close all browser windows (not just tabs) or restart the browser for the trust to take effect.

Local with Custom Domain (edit /etc/hosts)

myapp.local {
    tls internal
    reverse_proxy localhost:3000
}

Tip: Add 127.0.0.1 myapp.local to your /etc/hosts file.

7. Disabling or Restricting Automatic HTTPS

For internal-only services, testing, or when TLS is handled elsewhere (e.g., a load balancer), you may need to disable Caddy's automatic certificate management.

Disable Globally

{
    auto_https off
}

example.com {
    reverse_proxy localhost:3000
}

This disables automatic HTTPS for all sites but still serves on both HTTP and HTTPS if you provide a certificate manually.

HTTP-Only Site Block

http://internal.example.com {
    reverse_proxy localhost:3000
}

The explicit http:// prefix tells Caddy this site should only serve HTTP—no certificate obtained.

Disable Redirects Only

{
    auto_https disable_redirects
}

example.com {
    reverse_proxy localhost:3000
}

Caddy still obtains certificates and serves HTTPS, but won't redirect HTTP → HTTPS. Useful when a frontend proxy handles redirects.

8. Docker Configuration

docker-compose.yml

version: "3.9"

services:
  caddy:
    image: caddy:2-alpine
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./Caddyfile:/etc/caddy/Caddyfile
      - caddy_data:/data
      - caddy_config:/config
    restart: unless-stopped

  app:
    image: your-app:latest
    expose:
      - "3000"

volumes:
  caddy_data:    # Stores certificates - PERSIST THIS!
  caddy_config:

Caddyfile

app.example.com {
    reverse_proxy app:3000
}

Critical — PERSIST THIS! The caddy_data volume stores certificates. Losing it means re-requesting from Let's Encrypt (rate limits apply).

9. Common Issues & Fixes

Problem	Cause	Solution
"unable to obtain certificate"	DNS not pointed	Verify A record with `dig example.com`
"port 80 already in use"	Another service on 80	Stop Apache/nginx or change ports
"permission denied"	Can't bind to 80/443	Use setcap or run as root initially
"too many certificates"	Let's Encrypt rate limit	Wait a week or use staging CA
Certificate for wrong domain	Stale config	Delete /data/caddy/ and restart
"tls: private key does not match"	Mismatched key/cert files	Regenerate or match correct pair
HTTP-01 fails behind Cloudflare	Orange-cloud proxying blocks ACME	Set DNS record to "DNS only" (gray cloud) or use DNS challenge

Check if DNS is Correct

# Should return your server's IP
dig +short example.com

# Compare to your server
curl ifconfig.me

Check if Ports are Open

# Test from another machine
nc -zv your-server-ip 80
nc -zv your-server-ip 443

# Check what's using ports locally
sudo lsof -i :80
sudo lsof -i :443

Enable Debug Logging

{
    debug
}

example.com {
    reverse_proxy localhost:3000
}

Then: journalctl -u caddy -f

Still stuck? Use our SSL Checker Tool to verify your certificate is installed correctly, or try the Let's Encrypt Troubleshooting Demo for ACME-specific issues.

10. Caddy vs Other Web Servers

If you're choosing a web server primarily for HTTPS offload or TLS termination, here's how Caddy compares to the traditional options:

Feature	Caddy	nginx	Apache
Auto HTTPS	✅ Built-in	❌ Manual	❌ Manual
ACME client built-in	✅ Native	⚠️ Certbot	⚠️ Certbot
mTLS support	✅ Native	✅ Config	✅ Config
Config syntax	Simple	Complex	Complex
Zero-downtime reload	✅	✅	✅
HTTP/2	✅ Default	✅	✅
HTTP/3 (QUIC)	✅	❌	❌
Memory usage	Higher	Lower	Medium
Ecosystem	Growing	Massive	Massive

When to use Caddy

• You want TLS without thinking about it
• Simple reverse proxy needs
• Developer environments
• Small to medium deployments

When nginx/Apache might be better

• Extreme performance requirements
• Complex rewrite rules
• Existing infrastructure/expertise
• Specific module requirements

11. File Paths & Commands

Default Paths (Linux with systemd)

Item	Path
Caddyfile	/etc/caddy/Caddyfile
Certificates	/var/lib/caddy/.local/share/caddy/
Logs	journalctl -u caddy

Essential Commands

# Validate config
caddy validate --config /etc/caddy/Caddyfile

# Reload without downtime
caddy reload --config /etc/caddy/Caddyfile

# Format Caddyfile (fixes indentation)
caddy fmt --overwrite /etc/caddy/Caddyfile

# Test ACME without rate limits
caddy run --config /etc/caddy/Caddyfile --adapter caddyfile

# Trust local CA (for `tls internal`)
caddy trust

# View current config as JSON
caddy adapt --config /etc/caddy/Caddyfile
